PowerLite Pro Cinema LS9600e 3LCD Reflective Laser 1080p Projector

Contact Us 800.463.7766
Mon-Fri 6am-8pm, Sat 7am-4pm PT

A wireless 3LCD Reflective laser home theater projector with Absolute Black.

Experience a new era in home theater with the revolutionary Pro Cinema LS9600e projector. Featuring 3LCD Reflective laser technology, this groundbreaking home theater projector delivers an unprecedented Absolute Black contrast ratio, wider color gamut, richer colors and smoother gradations, with 1300 lumens of color brightness and 1300 lumens of white brightness1. The result is superior image quality that elevates any screening to an enthralling movie theater experience. Enjoy 1080p content in brilliant 2D and 3D with Super Resolution — you can also stream content with WirelessHD™. ISF® calibration tools ensure accurate performance. Plus, installation is easier and more flexible than ever.

    • Projection System: 3LCD Reflective, 3-chip technology
      Native Resolution: 1080p (1920 x 1080)
      Color Brightness: 1300 lumens1
      White Brightness: 1300 lumens1
  • Model: V11H559020KB
  • One measurement of brightness is not enough — look for both high color brightness and high white brightness.
    The Pro Cinema LS9600e has:
      Color Brightness: 1300 lumens1
      White Brightness: 1300 lumens1
  • Laser light source — lamp-free design ensures high-speed contrast control and wider color gamut with rapid warm-up and cool down
  • 3LCD Reflective technology — improved pixel density, increased aperture ratio and fast performance for incredibly smooth, film-like picture quality
  • Absolute Black contrast ratio — together, the 3LCD Reflective system and laser light source deliver unprecedented black levels, displaying zero lumens during full-black scenes
  • Full HD 1080p content in 2D and 3D — Super Resolution with Detail Enhancement and frame interpolation technology deliver a stunning viewing experience; RF 3D glasses included
  • Superior image quality — ISF calibration tools and THX® Display Certification ensure accurate and exceptional performance, the way filmmakers intended
  • Easy installation and image adjustments — 2.1x power zoom, power focus and extraordinary lens shift (90 percent vertical, 40 percent horizontal)
  • Lens position memory — store up to 10 settings in the projector memory, including zoom and focus positions for standard 16:9 or 4:3 projection areas, and 2.35:1 wide cinema ratio
  • Wirelessly transmit HD content — watch 1080p wirelessly; WirelessHD transmitter has five HDMI inputs, including one MHL-enabled HDMI port
  • Outstanding support — three-year limited warranty, dedicated toll-free support, Epson Home Service Program

What's in the box:

  • PowerLite Pro Cinema LS6900e projector
  • Power cord
  • Two 3D glasses
  • Two HDMI cable clamps
  • WirelessHD transmitter
  • Remote control with batteries
  • CHF3500 Ceiling Mount (shipped in a separate box)

Specifications Projector:


Projection System: 3LCD Reflective 3-chip technologyProjection Method: Front / rear / ceiling mountDriving Method: Epson Poly-silicon TFT Active Matrix, 0.74-inch wide panel Reflective HTPSPixel Number: 2,073,600 dots (1920 x 1080) x 3Color Brightness - Color Light Output: 1300 lumens1White Brightness - White Light Output: 1300 lumens1Aspect Ratio: 16:9 widescreen (4:3 resize) Compatible with 4:3 and 2.35:1 video formats with Normal, Full or Zoom ModesNative Resolution: 1080p (1920 x 1080)Resize: 16:10, 4:3Throw Ratio Range: 1.28 (Zoom: Wide), 2.73 (Zoom: Tele)Size - projected distance: 100" diagonal (wide: 9.3' – tele: 19.8')Keystone Correction: ±30 degreesContrast Ratio: Absolute Black (Full White 1300 lumens / Full Black 0 lumens)Color Processing: 10 bit (Partial 12 bit)Color Reproduction: Up to 1.07 billion colorsProjected Output: HD, 2D, 3D, 1080pLight Source Life: Up to 30,000 hours (ECO Mode)2Laser Type: Laser Diode 33.7 mW (Output)

Projection Lens:


Type: Powered Optical zoom/ Powered focusF-number: 2.5 – 3.7Focal Length: 21.3 mm – 44.7 mmZoom Ratio: 1.0 – 2.1Lens Shift:
  • Vertical: 90% max (up and down with horz. centered)
  • Horizontal: 40% max (left and right with vertical centered)
Lens Cover: Powered, Slide Lens Shutter

Other Home Projector:


Lens Position: the following 3 items are saved in memory: Lens Shift Position / Zoom Position / Focus PositionMemory Positions: 10 (Memory 1 – 10)Picture-in-Picture: Yes (HDMI® only)Lens Iris: Fine adjustmentsSuper Resolution: Off / 1 / 2 / 3 / 4 / 5Pull Down: (1080/24p) 10:10 pull downFrame Interpolation: Off / Low / Normal /High (2D and 3D Mode)Deinterlacing: Film / Auto, Video, OffTerminal Outputs: (2 x) configurable as Screen Power or Anamorphic Lens - Trigger On/Off (3.5 mm mini-stereo jack) each - 12 VDC 200 mA (max.)Epson Super White: Controlled automatically adjusting to HDMI source (Available at Natural / THX / Cinema / B&W Cinema / 3D Cinema / 3D THX, User selectable On/Off on OSD)Computer Compatibility: PC, Mac®

Parental Controls:


Power Button Lock: Hinders projector from being turned on without parental supervision

WirelessHD Transmitter:


Storage Temperature: 14° F to 140° F (-10° C to 60° C)Operating Altitude: 0 to 7500 ftPower Consumption: 11V 1.2AInput: HDMI x 5, including 1 MHL® enabledOutput: HDMI x 1, Optical Audio x 1, USB Type A x 1 (3D Glasses Charging)Safety: UL 60950-1 2nd edition (cTUVus Mark)EMC: FCC Part 15B Class BWireless: FCC Part 15 Subpart C 15.255Wireless HD Type: Beam Forming WirelessHD 1.0b 60 GHz Band (QPSK, 16-QAM, BPSK) 2 ch and 3 chDimensions: 6.9" x 5.0" x 2.0" (W x D x H)

General:


Weight: 39.7 lbsSecurity: Kensington Security Lock PortCase Color: Black

Projector Details:


Display Performance: 1920 x 1080 native 1080p; HD, 2D, 3D, 2D to 3D conversionColor Modes: Dynamic, Living room, Natural, THX, Cinema, B&W Cinema, 3D Dynamic, 3D Cinema, 3D THXInput Signal: HDMI: 480i/576i/480p/576p/720p/1080i/1080pInterfaces:
  • HDMI x 2
  • RS-232c x 1
  • RCA (composite) x 1
  • RCA (component) x 3
  • VGA D-sub 15 pin (computer input) x 1
  • Wired LAN (RJ45, 100 Mbps) for command and Control only x 1
Fan Noise: 19 dB – 28 dB

Projector Dimensions:


Including feet: 21.65" x 21.77" x 8.85" (W x D x H)

Remote Control:


Features: Front and rearOperating Distance: 19.7 ftOperating Angle:
  • Front: Right / Left: ±30 degrees
  • Upper / Lower: ±30 degrees
  • Rear: Right / Left: ±30 degrees
  • Upper / Lower: 0 – +60 degrees
See Full Specs Hide Full Specs

Epson Pro Cinema LS9600e Receives Highly Rated Award from Projector Central

"Accurate color is critical to good home theater, and the LS9600e delivers... ideal for the cinema purist who wants dead-on color accuracy." - Projector Central, December 4, 2014
Read More

Notes:

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

Specifications Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 30,000 hours is the estimated projector life when used in ECO Mode. Actual hours may vary depending on usage environment. The projector comes with a three-year limited warranty, described in the warranty statement.
