ColorWorks C3500 Color Label Printer

Contact Us 800.463.7766
Mon-Fri 6am-8pm, Sat 7am-4pm PT

With Epson's ColorWorks C3500 inkjet label printer, you can dramatically reduce label costs, increase operational efficiencies and print high-quality, durable labels on demand in four colors (CMYK) at speeds of up to 4 inches/second.

  • Model: C31CD54011
  • Ideal for high-mix, low-volume applications
  • Compact, robust design for commercial use
  • High print speed of up to 4 inches/second
  • High-quality four-color inkjet printing
  • Individual ink cartridges for efficient use of ink
  • Supports all major label applications
  • Easily adjusts to handle 1.2" to 4.4' widths
  • Rear-feed capability for fanfold and large rolls
  • Meets BS5609 certification for GHS labels
  • USB and Ethernet interfaces

What's in the box:

  • ColorWorks C3500
  • AC power adapter with line cord
  • Full capacity Ink cartridges
  • Sample label roll
  • Media output tray
  • Instruction sheet
  • CD with utilities and manuals

Print Other:


Printing Technology: MicroPiezo® inkjet technology, Automatic NozzleCheckingPrint Resolution:
  • Speed Mode: 360 dpi x 360 dpi
  • Quality Mode: 720 dpi x 360 dpi
Print Width: 4.1" (104mm) max.Print Speed:
  • High-speed mode: 360 dpi x 180 dpi
    • 2.7"/sec. (4.1" print width)
    • 3.3"/sec. (2.8" print width)
    • 3.7"/sec. (2.2" print width)
  • Fine mode: 360 dpi x 360 dpi
    • 1.4"/sec. (4.1" print width)
    • 1.7"/sec. (2.8" print width)
    • 1.9"/sec. (2.2" print width)

Ink:


Ink Type: Pigmented ink, individual CMYK cartridges1Ink Configuration:
  • GJIC22P(C)   Cyan    C33S020581
  • GJIC22P(K)   Black    C33S020577
  • GJIC22P(M)   Magenta C33S020582
  • GJIC22P(Y)   Yellow   C33S020583

General:


Operating Systems:
  • Windows® XP 32-bit (SP3)/64-bit (SP2)
  • Windows Vista® 32-bit/64-bit (SP2)
  • Windows 7 32-bit/64-bit (SP1)
  • Windows 8 32-bit/64-bit
Temperature:
  • Operating: 10-35 degrees C
  • Storage: -20-40 degrees C
Humidity:
  • Operating: 20-80% RH humidity
  • Storage: 5-85% RH humidity
Sound Level: Approx. 58 dBADimensions:
  • Printer: 12.2" x 11.1" x 10.3" (W x D x H)
  • Shipping: 17.5" x 15.5" x 16.8" (W x D x H)
Weight:
  • Printer (without ink): 26 lbs (12.2 kg)
  • Shipping: 41 lbs (12.2 kg)
Safety Approvals:
  • EMI: FCC / ICES-003 Class B
  • Safety standards: UL60950-1/CSA C22.2 No.60950-1
  • Warranty: One year depot repair

Fonts:


Barcode: UPC-A, UPC-E, JAN13(EAN), JAN8(EAN), Code39, ITF, Codabar, Code93, Code128, GS1-128, GS1DataBar Omnidirectional, GS1 DataBar Truncated, GS1DataBar Limited, GS1 DataBar Expanded, PDF417, QRCode, Maxi Code, GS1 DataBar Stacked, GS1 DataBarStacked Omnidirectional, GS1 DataBar ExpandedStacked, DataMatrix, Aztec Code2

Media Handling:


Width:
  • Roll feed: 1.2" – 4.25" (30 – 108mm)
  • Fan fold: 2.0" – 4.25" (50 – 108mm)
Type: Roll-fed or fanfold; die cut or continuous; single layeror adhesive labels on liner; plain paper, fine paper, PETfilm, syntheticThickness: 4.7 – 7.5mils (0.12 – 0.19mm)Roll Diameter:
  • O.D. 4.0" (102mm) max.
  • Core diameter 1.75" (44mm) to 2.25" (57mm)
Roll-fed Width: 1.2" – 4.25" (30 – 108mm)Sensors: Gap, black mark, media cutBlack Mark Size: Min. 0.20 x 0.16" (5.0 x 4.0mm) (W x H)Die-cut Label Gap: Min. 0.12" (3.0mm)

Connectivity:


Standard Connectivity: USB 2.0 High-speed, Ethernet 10/100 BASE-T

Display Terminal:


Ethernet: Ethernet 10/100 BASE-T

Power:


Rated Voltage: AC 100-240 VACRated Frequency: 50-60 HzPower Consumption:
  • Printing: 30 W (average printing)
  • Standby: 2.5 W
  • Power Off state: 0.3 W
Power Source: AC power adapter with line cord
See Full Specs Hide Full Specs

Notes:



Specifications Notes:
1Inkjet cartridge yields vary considerably for reasons including item printed, print settings, temperature and humidity. Yields may be lower when printing infrequently. A variable amount of ink remains in the cartridge after the "replace cartridge" signal. Ink from the first cartridge is used for priming the printer. Ink is used for both printing and print head maintenance.
2No character font or 1D/2D code font installed.
