Certified ReNew Projectors for Work PowerLite Pro G6800 XGA 3LCD Projector with Standard Lens
Discontinued

PowerLite Pro G6800 XGA 3LCD Projector with Standard Lens

Zoom In
PowerLite Pro G6800 XGA 3LCD Projector with Standard Lens
PowerLite Pro G6800 XGA 3LCD Projector with Standard Lens

Large-Venue Projector with Bright Performance and HDBase-T

Get uncompromising image quality and professional-grade reliability with the PowerLite Pro G6800 XGA large-venue projector with standard lens. Whether you're presenting in a conference room, auditorium, stage or house of worship, this powerful projector will keep your audience captivated. Incredible color brightness and XGA resolution means images are brighter, crisper and even more brilliant. Setup is a breeze with flexible, 360-degree installation and diverse connectivity options including HDBaseT. You'll stay in control with remote management functions and easily adapt to the environment with six optional lenses. Edge-blending capabilities enhance the experience with panoramic images and integrated curves and corners. Point and arc correction ensures that rectangular images are never compromised. And for the ultimate presentation, 3D stackable solutions and low-cost glasses take it all to the next level.

    • Projection System: High-aperture Epson 3-chip 3LCD technology
      Native Resolution: XGA (1024x768)
      Color Brightness: 7000 lumens1
      White Brightness: 7000 lumens1
      Throw Distance Calculator
  • Model: V11H532020
Find Accessories Support View Service Plans
Bright and Colorful
Features 7000 lumens of color brightness (color light output)1 and 7000 lumens of white brightness (white light output)1.
XGA Resolution
1024 x 768 resolution
HDBaseT
Combines HDMI, ethernet and RS-232 into one cable
Advanced Edge Blending
Get seamless panoramic, multi-screen edge blending on horizontal or vertical walls, with curved surface and corner wall support.
Optional Lenses
Interchangeable lens options with varying ranges for optimal placement and flexibility
Lens Shift
Equipped with horizontal and vertical lens shift
  • Up to 3x Brighter Colors and reliable performance — 3LCD, 3-chip technology*
  • One measurement of brightness is not enough — look for both high color brightness and high white brightness.
    The PowerLite Pro G6800 has:
      Color Brightness: 7000 lumens1
      White Brightness: 7000 lumens1
  • Crisp, clear resolution — XGA resolution for incredible images
  • Six optional lenses with lens shift — standard, wide, rear, middle or long-throw for complete flexibility and easy exchange
  • Versatile connectivity — easily integrate with any system; including HDBaseT
  • Convenient remote management — remotely monitor and control presentations; includes scheduling function
  • Built-in edge-blending technology — seamlessly project more than one image at a time


IMPORTANT SAFETY INFORMATION ABOUT USAGE ENVIRONMENTS FOR MOUNTED PROJECTORS ►

What's in the box:

  • Epson PowerLite Pro G6800 Projector
  • 1.8x standard zoom lens
  • Power cable
  • Computer cable (VGA)
  • Projector remote control with batteries
  • User manual CD
  • EasyMP® software CD
  • Quick Setup Sheet

  • Registration card
  • Password protection sticker
  • Lens lock screw

Specifications Projector:

Projection System: High-aperture Epson 3-chip, 3LCD technologyProjection Method: Front / rear / ceiling mountDriving Method: Epson Poly-silicon TFT Active MatrixPixel Number: 786,432 dots (1024x768) x 3Color Brightness - Color Light Output: 7000 lumens1White Brightness - White Light Output: 7000 lumens1Aspect Ratio: Supports 4:3, 16:9, 16:10Resolution: 1024x768 (XGA)Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050Lamp Type: 380 W UHELamp Life:
  • Normal mode: Up to 2000 hours2
  • ECO mode: Up to 4000 hours2
Brightness Uniformity: 90%Pixel Arrangement: Cross stripeThrow Ratio Range: 1.29 – 2.35Size - projected distance: 50" – 300"Keystone Correction:
  • Horizontal: ±30 degrees
  • Vertical: ±30 degrees
Contrast Ratio: 5,000: 1Color Processing: 10 bitColor Reproduction: Up to 1.07 billion colors

Effective Scanning Frequency Range:

Pixel Clock, Horizontal, Vertical:
    Pixel Clock
  • 13.5 MHz – 162 MHz (up to UXGA 60 Hz)
    • Horizontal
  • 15 KHz – 92 KHz
    • Vertical
  • 50 Hz – 85 Hz

General:

Temperature: 32° to 113° F (0° to 45° C)Humidity: Operation 20% - 80%, storage 10% - 90%Dimensions: 50.5 cm x 40.4 cm x 17 cm (width x depth x height) - without support feet and lensWeight: 21.5 lb (with standard lens)Security:
  • Security cable hole
  • Lens lock
  • Kensington® lock provision,

Projection Lens:

Type: Manual focus / zoomF-number: 1.65 – 2.55Focal Length: 21.28 mm – 37.94 mmZoom: Manual, Factor: 1, 1.8Zoom Ratio: Optical zoom 1.0 – 1.8Lens Shift:
    With standard lens
  • Vertical: ±57 degrees
  • Horizontal: ±30 degrees

Connectivity Projector:

Standard Connectivity: HDMI x 1, DisplayPort x 1, Computer: D-sub 15 pin x 1, Video-1: 5-BNC x 1, Video-2: RCA x 1, Composite video BNC x 1, S-Video x 1, audio input: mini stereo 3x, audio input: RCA (left and right) x 1, Network connection: RJ-45 x 1, 100 Mbps, USB Type-A x 1, Type-B x 1, Serial: RS-232c, hardwire remote jack x 1, monitor output: D-sub 15 pin x 1, HD BaseT x 1

Projector Details:

Display Performance:
  • NTSC: 480 line
  • PAL: 576 line
    • (depends on observation of the multi-burst pattern)
Color Modes: Photo, Presentation, Sport, sRGB, Theater, DICOM SIMInput Signal:
  • NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
  • 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
  • Pixel works: video chip
  • 3D Y/C separation, noise reduction motion compensated
  • Interlace-Progressive conversion (2 – 2, 3 – 2 film detection)
Interfaces:
  • HDMI x 1
  • DisplayPort x 1
  • Computer: D-sub 15 pin x 1
  • Video-1: 5-BNC x 1
  • Video-2: RCA x 1
  • Composite video: BNC x 1
  • S-Video x 1
  • Audio-in: Mini stereo x 3
  • Audio-in: RCA (L & R) x 1
  • Network: RJ-45 x 1, 100 Mbps
  • USB Type-A x 1, Type-B x 1
  • Serial: RS-232c
  • Hardwire Remote jack x 1
  • Monitor-Out: D-sub 15 pin x 1
  • HD BaseT x 1
Special Features: Instant On/Off, network management, Quick CornerFan Noise:
  • Normal mode: 39 dB
  • ECO mode: 31 dB

Projector Dimensions:

Including feet: With standard lens: 19.88" x 15.94" x 6.73" (W x D x H)Excluding feet and lens: 19.88" x 15.04" x 5.67" (W x D x H)

Remote Control:

Features: Power, source search selection, computer, video, A/V mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, help, menu, enter, esc andpointer functionsOperating Distance: 49 ftOperating Angle:
    Right / Left:
  • Front: ±60 degrees
  • Rear: ±30 degrees
    • Upper / Lower:
  • Front: ±20 degrees
  • Rear: +10 to -45 degrees

Power:

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz ACRated Voltage: AC 110 V - 240 V, 50 Hz - 60 HzPower Consumption:
  • Normal mode: 568 W
  • ECO mode: 421 W
  • Communication on: 3.3 W standby
  • Communication off: 0.41 W standby
See Full Specs Hide Full Specs
Print All Specs

Service Plans:

Need Support?

Get the latest drivers, FAQs, manuals and more for your Epson product.

Go to Support

Notes:

*Color Brightness (Color Light Output) in brightest mode, measured by a third-party lab in accordance with IDMS 15.4. Color Brightness will vary depending on usage conditions. Top-selling Epson 3LCD projectors versus top-selling 1-chip DLP projectors based on PMA Research sales data for Dec. 2015 through Nov. 2016.

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

Specifications Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
