TM-T88 ReStick Liner-free Label Printer

The high-quality, cost-effective TM-T88 ReStick liner-free label printer is ideal for food service, retail and grocery applications. Based on new technology, The TM-T88 ReStick label printer prints repositionable liner-free labels and receipts at a crisp 203 x 203 dpi. It supports continuous rolls for variable length label output and produces 60% more labels per roll than die-cut labels. And it is compatible with the TM-T88 series of printers, so no software changes or application development is required.

REPLACEMENT PRODUCT :
TM-L90 Plus Liner-free Compatible Label Printer
TM-L90 Plus Liner-free Compatible Label Printer
Model: View Main Product Page Learn More
  • Cost-effective liner-free label printing
  • Continuous roll for variable length label output
  • Produces 60% more labels per roll than die-cut labels
  • Available in two models: one for 2 1/4" and one for 3 1/8" paper widths
  • Uses MAXStick® silicone-free adhesive liner-free labels
  • Modified paper well, printhead and support rollers prevent jams due to adhesive
  • Supports a wide range of standard and wireless interfaces
  • Features enhanced 203 x 203 dpi and is compatible with standard TM-88s with an emulation

Print Other:


Printing Technology: Thermal line printingPrint Resolution: 203 dpi x 203 dpiPrint Speed: 5.91"/second (150mm) graphics and text

General:


Dimensions: 5.71 x 7.68 x 5.83” (W x D x H) (145 x 195 x 148mm)Weight: 3.96 lb (1.8 kg)Safety Approvals: Control Board:
  • EMI standards: FCC/ICES-003 Class A
  • Safety standards: UL1950/CSA C22.2 No. 950
  • Font emulation: TM-T88 Series (180 dpi) font emulation available
Case Color: Epson Dark Gray, Epson Cool White

Print Fonts:


Column Capacity:
  • 3.125" (80mm):
    • Normal mode (203 dpi) 48/64/57 columns
    • Emulation mode (180 dpi) 44/57/57 columns
  • 2.25" (58mm):
    • Normal mode (203 dpi) 35/46/42 columns
    • Emulation mode (180 dpi) 42/46/35 columns
Character Size:
  • 33.125" (80mm):
    • Normal mode (203 dpi) 1.25 x 3.0/0.88 x 2.13/1.125 x 3.0
    • Emulation mode (180 dpi) 1.25 x 3.0/0.88 x 2.13/1.125 x 3.0
  • 2.25" (58mm):
    • Normal mode (203 dpi) 1.25 x 3.0/0.88 x 2.13/1.125 x 3.0
    • Emulation mode (180 dpi) 1.125 x 3.0/0.88 x 2.13/1.25 x 3.0
Fonts:
  • 3.125" (80mm):
    • Normal mode (203 dpi) 12 x 24/9 x 17/10 x 24
    • Emulation mode (180 dpi) 13 x 24/10 x 17/10 x 24
  • 2.25" (58mm):
    • Normal mode (203 dpi) 12 x 24/9 x 17/10 x 24
    • Emulation mode (180 dpi) 10 x 24/9 x 17/12 x 24
Character Set: 95 Alphanumeric, 48 International, 128 x 11 Graphic (including user-defined page) Traditional/Simple Chinese, Thai, Japanese, KoreanBarcode: UPC-A/E, CODE 39/93/128, EAN8/13, ITF, CODABAR, 2D symbols: PDF417, QR-CODE

Media Handling:


Tested Media: Visit www.epson.com/lfctestedmedia for a complete list.Thickness: 82.5 ± 3.8 µmMedia Dimensions:
  • 3.125" (80mm): 3.12" ± 0.016"(W) x 3" +0.15/-0.06" dia. (79.4 ± 0.4(W) x 76.2 +3.8/-1.6 mm)
  • 2.25" (58mm): 2.25" +0.016/-0.008" x 3" +0.15/-0.06" dia. (57.2 + 0.4/-0.2(W) x 76.2 +3.8/-1.6 mm)

Connectivity:


Standard Connectivity:
  • RS-232C, IEEE 1284 parallel
  • RS-485
  • high-speed USB
  • 10/100Base-T/TX
  • wireless

POS Details:


Reliability:
  • MTBF: 360,000 hours
  • MCBF: 48,000,000 lines
  • Autocutter: 600,000 cuts
Data Buffer:
  • Receive: 45 bytes or 4KB, selectable
  • user-defined: 12KB
  • macro: 2KB
  • NV graphics: 256KB
  • NV user: 1KB
D.K.D.: 2 driversOptions: Power supply cover, PS-180 AC adapter, wall-hanging bracket, paper roll spacer, affixing tape and Connect-It interfaces1

Power:


Power Consumption: Approx. 1.8 A (mean)Power Source: 24 VDC ± 7%

Notes:



Specifications Notes:
1To find out more about our line of Connect-It™ interfaces, talk to your Epson Sales Representative.

Inch values are approximate
dpi: dots per 25.4mm (dots per inch)
cpi: characters per 25.4mm (characters per inch)
lps: lines per second
