DFX-5000 Impact Printer
Zoom In
Close
- Printing Method: 9-pin impact wide carriage
Print Speed:
High Speed Draft: 560 cps (10 cpi)
Draft : 504 cps (12 cpi)
Near Letter Quality : 101 cps (12 cpi)
Character Sets: 13 international, 11 code tables, 2 character tables (IBM)
Fonts: 6 bitmapped
Paper Paths: Dual push tractors/paper paths: automatic back out and loading; automatic paper thickness width adjustment; optional pull tractor
Paper Feed Speed: 17 ms/line at 1/6" line feeding; 10" per second continuous feed;26 ms/line intermittent speed
Maximum Forms:
Front : Original + 5 copies
Rear : Original + 3 copies
Input Buffer: 0KB or 20KB (selectable)
Interfaces: 8-bit parallel, RS232C serial; optional Type-B
Emulations: ESC/P; IBM ProPrinter II standard
Dimensions: 14.5" H x 15.0" D x 27.6" W, 63.9 lb
Voltage: 103.5 to 132V AC
Sound Level: 55 dB(A)
Print Head Life: 300 million characters @ 14 dots per character
MTBF: 8,000 POH @ 25% duty cycle- Model: C112001
