For Work Printers Impact Dot Matrix FX-2190II Impact Dot Matrix Printer

FX-2190II Impact Dot Matrix Printer

Contact Us 800.463.7766
Mon-Fri 7am-4pm PT

Wide-format impact printers built for demanding print environments.

The Epson FX-2190II Impact Printer offers the durability and productivity needed for critical daily print requirements. These reliable 9-pin, wide-format impact printers boast a long life cycle, a 3-year limited warranty and speeds up to 738 cps1. Their up-to-12-million-character ribbon cartridge2 reduces user interventions as well as cost per page. Engineered for seamless integration into virtually any system, they include Epson ESC/P®, IBM® PPDS and MICROLINE® printer languages. Ideal for harsh environments, these workhorses race through cut-sheet, continuous or multipart forms up to 7 pages thick, and feature an intuitive control panel for easy setup and operation.

  • Model: C11CF38201
Our Price :


Protect Your Product

Add a plan with your new product now.
  • Extreme reliability ― long life cycle; durable design with very few moving parts; withstands dust, humidity and extreme temperatures
  • Low cost of ownership ― up-to-12-million-character ribbon cartridge2 offers a low cost per page and reduces the frequency of user interventions
  • Powerful productivity ― ultra fast, wide-format, 9-pin printer speeds through multipart forms and reports at up to 738 cps1
  • Seamless integration with both new and legacy systems ― includes Epson ESC/P, IBM PPDS and MICROLINE printer languages for greater flexibility
  • Advanced paper handling ― simple paper path for remarkable reliability; accommodates cut-sheet paper and continuous or multipart forms up to 7 pages thick
  • Easy setup and operation ― user-friendly control panel with intuitive setup and configuration features
  • Low power consumption ― ENERGY STAR® V2.0 compliant
  • Multiple connectivity options ― Parallel and USB connectivity
  • Serial port and Ethernet compatible ― network card supports IPv63

Eco Features

  • RoHS compliant
  • Recyclable product4
  • Epson America, Inc. is a SmartWaySM Transport Partner5

Better Products for a Better Future™
For more information on Epson's environmental programs, go to

What's in the box:

  • Epson FX-2190II Impact Printer
  • AC Adapter
  • User’s Manual/Start Here Guide
  • Setup Guide
  • CD Driver
  • Warranty Certificate

Print Other:

Printing Technology: 9-pin, serial impact dot matrixPrint Speed:
  • Ultra Speed Draft: 738 cps (12 cpi), 615 CPS (10 cpi)1
  • High Speed Draft: 612 CPS (10 cpi)1
  • Draft: 463 CPS (10 cpi)1
  • Letter Quality: 115 CPS (10 cpi)1
Note: Normal print speed is achieved when printer safety cover is fully closed.Print Direction: Bidirectional logic seeking for text and graphics printing. Unidirectional text or graphics printing can be selected using software commands.

Characters & Lines:

Character Sets:
  • 13 character tables
  • 13 international countries character sets
Resident Bitmapped Fonts:
  • Ultra Speed Draft: 10, 12 cpi
  • High Speed Draft: 10, 12, 15, 17, 20 cpi
  • Draft: 10, 12, 15, 17, 20 cpi
  • NLQ (Roman/Sans Serif): 10, 12, 15, 17, 20 cpi, proportional
Bar Code Fonts: EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5Formatting: 1/6" programmable in 1/432" increments
Line spacing: 6 lines per inch (lpi) default (8 lpi option available on FX-2190II Series Oki Data Mode Only)


Sound Level: Noise: 55 dBA (ISO 7779 pattern)Dimensions: 24.1" x 14.8" x 6.9" (W x D x H)Weight: 20.7 lb.Safety Approvals: UL62368-1, CAN/CSA C22.2 No. 60950-1, IEC/EN62368-1 EMI: FCC part15 subpart B class A, ICES-003 Class A, EN55032 (CISPR pu.32) class A, As/NZS CISPR32 class A CE Markings: EN62368-1, EN55032 class A, EN61000-3-2, EN61000-3-3, E55024

Paper Handling Impact:

Forms: Continuous multipart, original plus 5 carbonless copies, 1 + 6 copies with pull tractor (optional), maximum thickness .018"Width:
  • Single Sheet: 3.9" to 16.5"
  • Continuous: 4.0" to 16.0"
  • Cut-sheet Feeder: 7.2" to 16.5"
Envelopes: No. 6 envelopes
No. 10 envelopesLength:
  • Single Sheet: 3.9" to 14.3"
  • Continuous: 4.0" to 22.0"
  • Cut-sheet Feeder: 10.1" to 14.0"
Paper Feed Mechanism:
  • Friction feed (front, rear)
  • Push tractor (front, rear)
  • Pull tractor (front, bottom, rear)
  • Push and pull tractor (front, rear)
  • Roll paper holder (optional)
Paper Feed Speed: 45 milliseconds per 1/6", 5.3" per second continuous feedPaper Path:
  • Manual Insertion: Front or rear in, top out
  • Cut-sheet Feeder: Rear in, top out
  • Tractor: Front rear or bottom in, top out
  • Pull/Push Tractor: Front or rear in, top out

Impact Printer Details:

Software Drivers: OS Support: Microsoft® Windows Vista®; Windows® 7, XP, 8, 10; Windows Server® 2003, 2008, 2012, 2016Printer Language:
  • Epson ESC/P
  • Oki Data MICROLINE (Oki Data Mode only)
Input Buffer: Size: 128KbInterfaces:
  • Standard: Bidirectional Parallel (IEEE 1284 Nibble Mode supported)
  • USB 2.0 Optional (Factory configuration only): Serial Interface Board (FX-2190II N only)
  • Network 10/100Base-TX Interface Board (FX-2190II N only)
Control Panel: Font, Pitch, Pause, Tear-off/Bin selection, Line feed/Form feed, Load/Eject, Micro-adjust, Reset, Self test, Data dump, and Default setting selection


MTBF: 25,000 POH (25% duty cycle)MVBF: 52 million lines (not including printhead)Print head life: 400 million characters at 14 dots / character2Ribbon life: 12 million characters at 14 dots / character2


Rated Voltage: AC 100 V to 240 VRated Frequency: 50 to 60 HzPower Consumption:
  • Operating Mode: Approx. 57 W (ISO/IEC 10561 Letter pattern)
  • Ready Mode: Approx. 12 W
  • Sleep Mode: < 0.04 W (Network model)
  • ENERGY STAR Compliant: Certified with V2.0
Input voltage range: AC 90 to 264 VInput frequency range: 49.5 to 60.5 Hz


1 Based on Ultra Speed Draft Mode at 12 cpi.

2 Based on Draft Mode printing.

3 Only available on the FX-2190II N model.

4 For convenient and reasonable recycling options, visit

5 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
