Home For Work Projectors Large Venue PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
DISCONTINUED

PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens

Zoom In
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens
PowerLite Pro G6570WUNL WUXGA 3LCD Projector without Lens

    • Projection System: High-aperture Epson 3-chip 3LCD technology
      Native Resolution: WUXGA (1920 x 1200)
      Color Brightness: 5200 lumens1
      White Brightness: 5200 lumens1
      Throw Distance Calculator
  • Model: V11H700920
Find Accessories Support View Service Plans
REPLACEMENT PRODUCT :
EB-PU1006W WUXGA 3LCD Laser Projector with 4K Enhancement
EB-PU1006W WUXGA 3LCD Laser Projector with 4K Enhancement
Model: View Main Product Page Learn More
Bright and Colorful
Features 5200 lumens of color brightness (color light output)1 and 5200 lumens of white brightness (white light output)1.
WUXGA Resolution
1920 x 1200 Full HD widescreen resolution
Edge Blending
Use multiple projectors to overlap images, and there are no bright spots where the overlap occurs – providing dynamic, seamless projection.
360-Degree Installation
Can be rotated in any direction for flexible, off-axis positioning – great for projecting on the ceiling or floor or as part of a rear-projection system.
Optional Lenses
Interchangeable lens options with varying ranges for optimal placement and flexibility
Lens Shift
Equipped with horizontal and vertical lens shift
  • 3x Brighter Colors and reliable performance — 3LCD, 3-chip technology*
  • One measurement of brightness is not enough — look for both high color brightness and high white brightness.
    The PowerLite Pro G6570WUNL has:
      Color Brightness: 5200 lumens1
      White Brightness: 5200 lumens1
  • Widescreen, Full HD performance — WUXGA (1920 x 1200) resolution supports Full HD for presentations, videos, digital signage and more
  • Versatile connectivity — easily integrate with any system; supports the latest connectivity options, including HDBaseT, HDMI and DisplayPort
  • Seamless control protocol support — compatible with Crestron, AMX, Extron XTP and Control4 Simple Device Discovery Protocol (SDDP)
  • Five optional lenses with lens shift — including rear-, middle- and long-throw lenses for complete flexibility and easy exchange (lenses are not included)
  • Easy installation features — built-in Edge Blending, 360-degree installation flexibility and simple cloning functions
  • Advanced collaboration features — simultaneously project from multiple devices over the network with Multi-PC projection, or side-by-side from different sources with Split Screen2
  • Convenient remote management — remotely monitor and control the projector; includes scheduling function
  • Industry-leading service and support — long-life air filter and easy maintenance tools, plus peace-of-mind ownership with next-business-day replacement3


IMPORTANT SAFETY INFORMATION ABOUT USAGE ENVIRONMENTS FOR MOUNTED PROJECTORS ►

What's in the box:

  • Epson PowerLite Pro G6570WUNL Projector
  • Lens NOT included
  • Power cable
  • Computer cable (VGA)
  • Projector remote control with batteries
  • User manual CD
  • EasyMP® software CD
  • Quick Setup Sheet
  • Lens lock screw

Specifications Projector:

Projection System: High-aperture Epson 3-chip, 3LCD technologyProjection Method: Front / rear / ceiling mountDriving Method: Epson Poly-silicon TFT Active MatrixPixel Number: 2,304,000 dots (1920 x 1200) x 3Color Brightness - Color Light Output: 5200 lumens1White Brightness - White Light Output: 5200 lumens1Aspect Ratio: Supports 4:3, 16:9, 16:10Resolution: 1920 x 1200 (WUXGA)Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050Lamp Type: 380 W UHELamp Life:
  • Normal mode: Up to 2500 hours2
  • ECO mode: Up to 4000 hours2
Brightness Uniformity: 90%Pixel Arrangement: Cross stripeThrow Ratio Range: (For Standard Lens) 1.26 – 2.76Size - projected distance: 50" – 300"Keystone Correction:
  • Horizontal: ±30 degrees
  • Vertical: ±30 degrees
Color Reproduction: Up to 1 billion colors

Effective Scanning Frequency Range:

Pixel Clock, Horizontal, Vertical:
    Pixel Clock
  • 13.5 MHz – 162 MHz (up to UXGA 60 Hz)
    • Horizontal
  • 15 KHz – 92 KHz
    • Vertical
  • 50 Hz – 85 Hz

General:

Temperature: 32° to 113° F (0° to 45° C)Weight: 21.5 lb (with standard lens)Security:
  • Security cable hole
  • Lens lock
  • Kensington® lock provision,

Projection Lens:

Type: (For Standard Lens) Manual focus / zoomF-number: (For Standard Lens) 1.65 – 2.55Focal Length: (For Standard Lens) 21.28 mm – 37.94 mmZoom Ratio: (For Standard Lens) Optical zoom 1.0 – 1.8Lens Shift:
    (For Standard Lens)
  • Vertical: ±67 degrees
  • Horizontal: ±30 degrees

Projector Details:

Display Performance:
  • NTSC: 480 line
  • PAL: 576 line
    • (depends on observation of the multi-burst pattern)
Input Signal:
  • NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
  • 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
  • Pixel works: video chip
  • 3D Y/C separation, noise reduction motion compensated
  • Interlace-Progressive conversion (2 – 2, 3 – 2 film detection)
Interfaces:
  • HDMI x 1
  • DisplayPort x 1
  • Computer: D-sub 15 pin x 1
  • Video-1: 5-BNC x 1
  • Video-2: RCA x 1
  • Composite video: BNC x 1
  • S-Video x 1
  • Audio-in: Mini stereo x 3
  • Audio-in: RCA (L & R) x 1
  • Network: RJ-45 x 1, 100 Mbps
  • USB Type-A x 1, Type-B x 1
  • Serial: RS-232c
  • Hardwire Remote jack x 1
  • Monitor-Out: D-sub 15 pin x 1
Fan Noise:
  • Normal mode: 39 dB
  • ECO mode: 31 dB

Projector Dimensions:

Including feet: With standard lens: 19.88" x 15.94" x 6.73" (W x D x H)Excluding feet and lens: 19.88" x 15.04" x 5.67" (W x D x H)

Remote Control:

Features: Power, source search selection, computer, video, A/V mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, help, menu, enter, esc andpointer functionsOperating Distance: 49 ftOperating Angle:
    Right / Left:
  • Front: ±60 degrees
  • Rear: ±30 degrees
    • Upper / Lower:
  • Front: ±20 degrees
  • Rear: +10 to -45 degrees

Power:

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz ACPower Consumption:
  • Normal mode: 528 W
  • ECO mode: 421 W
  • Communication on: 2.8 W standby
  • Communication off: 0.31 W standby
See Full Specs Hide Full Specs
Print All Specs

Need Support?

Get the latest drivers, FAQs, manuals and more for your Epson product.

Go to Support

Notes:

* Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions. Leading Epson 3LCD business and education projectors compared to leading 1-chip DLP projectors, based on NPD data for June 2013 through May 2014 and PMA Research data for Q1 through Q3 2013.

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 Consult your user manual for input combinations.

3 Expedited shipping not available in all areas. Road Service orders must be in by 3 p.m. Eastern Time for Next-Business-Day delivery.

Specifications Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.


Epson business and education projectors have 3x Brighter Colors than their leading competitive 1-chip DLP projectors. Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions. Based on NPD data for June 2013 through May 2014 and PMA Research data for Q1 through Q3 2013.
