Pro L1100UNL Laser WUXGA 3LCD Projector with 4K Enhancement without Lens

Premium large-venue laser projector with 4K Enhancement*.

The Pro L1100UNL large-venue projector combines a laser light source, inorganic components and 3LCD technology for powerful, uncompromising images. Ideal for events staging, auditoriums and sanctuaries, this innovative projector features native WUXGA performance with Epson® 4K Enhancement Technology^*. Offering extraordinary color brightness, Epson 3LCD projectors ensure brilliant images. Delivering 6,000 lumens of color brightness and 6,000 lumens of white brightness¹, the L1100U's laser light source also provides 20,000 hours of virtually maintenance-free operation². Plus, its exceptional integration capabilities include diverse connectivity such as HDBaseT™ and ten optional powered lenses (sold separately) with lens shift and lens memory.

Model: V11H735920

Find Accessories Support View Service Plans

REPLACEMENT PRODUCT :

EB-PU1006W WUXGA 3LCD Laser Projector with 4K Enhancement

Model: View Main Product Page Learn More

Overview

One measurement of brightness is not enough — look for both high color brightness and high white brightness.
The Pro L1100UNL has:
Exceptional Full HD widescreen display — native WUXGA (1920 x 1200) with 4K Enhancement^*for presentations, videos, digital signage and more
Solid-state laser light source — virtually maintenance-free 20,000-hour laser light source with no lamps²
Innovative 4K Enhancement Technology^* — doubles the number of pixels from 2.3 million (WUXGA) to 4.6 million for extraordinary image and video quality
Versatile connectivity — supports the full range of inputs, including HDBaseT, HDMI®, DVI-D, SDI, VGA and 5-BNC, for easy integration with any system
Ten optional interchangeable lenses — with powered lens shift and lens memory, including an ultra short-throw lens for shallow spaces (sold separately)
Web-based remote management — control and monitor projector status via a Web browser
Dynamic projection capabilities — advanced built-in Edge Blending, image warping and curved-surface correction technologies for a variety of applications
Professional installation features — full 360-degree installation flexibility, including Portrait Mode
Industry-leading service and support — get peace-of-mind ownership with free next-business-day replacement³, plus postage-paid returns

Eco Features

RoHS compliant
Recyclable product⁴
Epson America, Inc. is a SmartWay™ Transport Partner⁵

Better Products for a Better Future™
For more information on Epson's environmental programs, go to www.epson.com/environment

IMPORTANT INFORMATION ABOUT USAGE ENVIRONMENTS ►

What's in the box:

Pro L1100UNL projector
Power cable
Computer cable (VGA)
Projector remote control with batteries
User manual CD
EasyMP software CD
Quick Setup Sheet
Lens lock screw

Specifications

Specifications Projector:

Projection System: High-aperture Epson 3-chip, 3LCD technologyProjection Method: Front / rear / ceiling mountDriving Method: Epson Poly-silicon TFT Active MatrixPixel Number: 2,304,000 dots (1920 x 1200) x 3Color Brightness - Color Light Output: 6000 lumens¹White Brightness - White Light Output: 6000 lumens¹Aspect Ratio: Supports 4:3, 16:9, 16:10Resolution: 1920 x 1200 (WUXGA)Resize: 640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050Brightness Uniformity: (typical) 90%Pixel Arrangement: Cross stripeThrow Ratio Range: (For Standard Lens) 1.45 – 2.32Size - projected distance: 50" – 300"Keystone Correction:

Horizontal: ±30 degrees
Vertical: ±45 degrees

Contrast Ratio: 2,500,000:1Color Processing: 10 bitColor Reproduction: Up to 1 billion colors

Effective Scanning Frequency Range:

Pixel Clock, Horizontal, Vertical:

Pixel Clock

13.5 MHz – 162 MHz (up to UXGA 60 Hz)

Horizontal

15 KHz – 92 KHz

Vertical

50 Hz – 85 Hz

General:

Temperature: 32° to 113° F (0° to 45° C)Weight: 41.2 lb without lensSecurity:

Security cable hole
Lens lock
Kensington® lock provision,

Projection Lens:

Type: (For Standard Lens) Powered shift/focus / zoomF-number: (For Standard Lens) 1.70 – 2.30Focal Length: (For Standard Lens) 24.0 mm – 38.2 mmZoom Ratio: (For Standard Lens) Optical zoom 1.0 – 1.6xLens Shift:

(For Standard Lens)

Vertical: ±67 degrees
Horizontal: ±30 degrees

Video:

Video Processing:

Analog: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
HDMI: 480i / 576i / 480p / 576p / 720p /1080i / 1080p
DVI-D: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p

Video Standards:

3D Y/C separation, 3D noise reduction, mosquito noise reduction
DCDi — Directional Correlational DeinterlacingMotion-compensated Interlace-Progressive conversion (2:2, 3:2 film detection)

Super Resolution:

FineFrame Interpolation
8:8 Pull-down Processing
Closed Captioning

Connectivity Projector:

Standard Connectivity:

Wired: Integrated 100Mbps
Wireless: Optional — 802.11b/g/n
Wireless Security: WPA-PSK (TKIP/AES) / WPA2-PSK(TKIP/AES)

Remote Control and Management:

Epson EasyMP® Monitor
Network projection
Multi-projection
AMX® Device Discovery
Crestron® Integrated Partner and Crestron RoomView®
Extron® IP Link and XTP
PJLink

Projector Details:

Display Performance:

NTSC: 480 line
PAL: 576 line

Input Signal:

NTSC/NTSC4.43/PAL/M-PAL/N-AL/PAL60/SECAM/480i/576i/480p/576p/720p/1080i/1080p
Pixelworks®:Video Chip 3D Y/C separation, noise reduction motion compensated Interlace-Progressive conversion (2 - 2, 3 - 2 film detection)

Interfaces:

DVI-D x 1
HDMI x 1
HDBaseT x 1
5-BNC, VGA x 1
Audio in: Mini
Stereo x 3
Variable audio out: Mini Stereo x 1
USB connector Type B x 1: For service only
USB connector Type A x 1: For wireless only
Monitor out: Mini D-sub 15 pin x 1
Serial: RS-232c x 1

Speaker: YesFan Noise:

Normal mode: 34 dB
ECO mode: 28 dB

Audio Output: Variable audio out: Mini Stereo x 1

Projector Dimensions:

Excluding feet and lens: 23.07 x 19.37 x 7.76 (W x D x H)Including feet - with standard lens: 23.07 x 19.37 x 8.31 (W x D x H)

Remote Control:

Features: Power, source search selection, lens shift, zoom, focus, test pattern selection, A/V Mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, help, menu, enter, esc and pointer functionsOperating Distance: 49 ftOperating Angle:

Right / Left:

Front: ±60 degrees
Rear: ±30 degrees

Upper / Lower:

Front: ±45 to ±15 degrees
Rear: ±10 to ±50 degrees

Power:

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz ACPower Consumption:

Normal mode:479 W
ECO mode: 327 W
Communication on: 2.0 W standby
Communication off: 0.28 W standby

See Full Specs Hide Full Specs

Print All Specs

Accessories

Service Plans

Service Plans:

SKU

Price
2-Year Exchange - Extended Service Plan

SKU:

EPPEXPC2

Price:

$1,019.00

Added to Your Shopping Cart
1-Year Exchange - Extended Service Plan

SKU:

EPPEXPC1

Price:

$589.00

Learn More

Support

Need Support?

Get the latest drivers, FAQs, manuals and more for your Epson product.

Go to Support

Notes:

^* 4K Enhancement Technology shifts each pixel diagonally by 0.5 pixels to double the resolution and surpass Full HD image quality.
¹ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
² No required maintenance for the light source and filter up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period. The projector has a limited warranty of 3 years or 20,000 hours, whichever comes first.
³ Expedited shipping not available in all areas. Road Service orders must be in by 3 p.m. Eastern Time for Next-Business-Day delivery.
⁴ For convenient and reasonable recycling options, visit www.epson.com/recycle
⁵ SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
