OmniLink TM-T88V-DT Intelligent Printer

Contact Us

562-276-1314

Zoom In
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer
OmniLink TM-T88V-DT Intelligent Printer

The OmniLink TM-T88V-DT is designed to offer retailers a POS system with maximum computing power and configuration flexibility. It includes a retail-hardened PC with a POSReady 7, Windows® 7 Pro or Linux operating system powered by an Intel Atom 1.86GHz processor. Optimized for stability and performance, it is all integrated into an ultra-small footprint and is ideal for retailers looking to implement mobile POS, Web-based POS configurations and kiosk applications.

Request More Info
Find Accessories Support
  • Printer with retail-hardened PC
  • POSReady 7, Windows® 7 Pro or Linux OS
  • Ethernet, optional Wireless-N connectivity
  • Includes multiple USB ports and a built-in VGA for POS peripheral connectivity
  • Mobile POS supports web-based printing from any mobile device
  • Intel® Atom™ processor supports a variety of thin client or Web POS configurations
  • Print speeds up to 300mm/sec
  • Paper-saving features reduce paper usage up to 30%

Print Other:

Printing Technology: Thermal line printingPrint Speed:
  • Max. 11.8"/sec (300mm) graphics and text
  • 2.4"/sec for ladder and 2D barcodes

General:

Server Systems: HTTP server (Apache)Dimensions: 5.71" x 10.98" x 7.20" (145 x 279 x 183 mm) (W x D x H)Weight: 7.05 lb (3.2 kg)Safety Approvals:
  • EMI standards: FCC/ICES-003 Class A
  • Safety standards: UL1950/CSA C22.2 No. 950
Case Color: Epson Black (EBCK), Epson White (ENN8.5)

Print Fonts:

Column Capacity:
  • 80mm: 42/56 columns
  • 58mm model: 30/40 columns
Character Size:
  • Font A: 1.41 x 3.39
  • Font B: 0.99 x 2.40 (W x H mm)
Fonts:
  • Font A (default): 12 x 24
  • Font B: 9 x 17 (including 2-dot horizontal spacing)
Character Set: 95 Alphanumeric, 18 International, 128 x 43 Graphic (including user-defined page), Traditional/Simple Chinese, Thai, Japanese, KoreanBarcode: UPC-A/E, CODE 39/93/128, EAN8/13, ITF,CODABAR 2D symbols: PDF417, QR-CODE,MaxiCode, Composite Symbology, GS1-128, GS1DataBar Omnidirectional/Truncated/Limited/Expanded

Media Handling:

Thickness: 55 – 80 µmMedia Dimensions:
  • 80mm: 3.13" ± 0.02" x 3.27" diameter(79.5 ± 0.5 (W) x 83mm)
  • 58mm: 2.26" ± 0.02" x 3.27" diameter(57.5 ± 0.5 (W) x 83mm)

Connectivity:

Standard Connectivity:
  • USB 2.0 x 6, 100 Base-TX / 10 Base-T Ethernet compliant interface
  • VGA x 1 (D-sub 15pin female)
  • x 1 DisplayPort
  • x 1 (3.5mm stereo mini jack) for external
  • speaker output
  • x 1 for cash drawer
  • x 1 RS-232
Printer Control: Can control printing on up to 20 Ethernet interface or TM series printers equipped with a wireless LAN interface

Control Board:

Software: Intelligent Software: WebPOS Configuration, ePOS-Device, Preboot Execution Environment (PXE)

Hardened PC:

Processor: Intel® Atom™ Processor (1.86GHz)Interface: Ethernet, optional Wireless-N connectivitySystem Memory: 4.0GB (DDR3-1066)Operating System:
  • Windows® Embedded POSReady 7
  • Linux

POS Details:

Reliability:
  • MTBF 360,000 hours
  • MCBF 70,000,000 lines
  • Autocutter 2 million cuts
Data Buffer:
  • Receive: 45 bytes or 4KB, selectable
  • user-defined: 12KB; macro: 2KB
  • NV graphics: 256KB
  • NV user: 1KB
  • page mode area: 106K
D.K.D.: 2 driversSoftware Included: Drivers and setup utility are available on CD or atpos.epson.comOptions: Autocutter, Near-end sensor

Power:

Power Consumption: Operating: approx. 1.8 A (mean)Power Source: 24 VDC ± 7%
